Cutting Machine

1700-XA

Auto Cutter that is ideal finishing equipment for Flexible and Rigid materials
Auto cutter for wide format finishing
Horizontal electric trimmer
Bi-Directional cutting
Unique air driving system
1700-XA
Brief
Details
Performance
Parameter
Quote Now >
1700-XA
1700-XA
1700-XA
1700-XA
1700-XA
1700-XA
1700-XA
1700-XA
1700-XA
1700-XA
1700-XA
1700-XA
1700-XA
Horizontal cutting machine is the ideal to cut materials up to 10mm in thickness. The sliding carrier has two tungsten blades for Bi-Directional, provide extra sharpness and lifetime.

Unique air driving system is more powerful and faster compared to electric device. LED illuminated backlighting along cutting edge creates accurate alignment. Equipped with roll holder to cut from roll medias.
Details
1
2
3
4
1.
Horizontal cutting machine to 10mm in thickness
2.
The sliding carrier has two tungsten blades for Bi-Directional
3.
Unique air driving system is more powerful and faster
4.
Equipped with front roll holder
Performance
LED illuminated cutting
LED illuminated backlighting along cutting edge creates accurate alignment.
Bi-Directional cutting
The sliding carrier has two tungsten blades for Bi-Directional, provide extra sharpness and lifetime.
Unique air driving system
Unique air driving system is more powerful and faster compared to electric device.
Equipped with roll holder
Equipped with roll holder to cut from roll medias.
Parameter
Cutting Width 1620mm
Cutting Thickness 10mm
Cutting Speed 1m/s
Bi-Directional Cutting Yes
LED illuminating Yes
Blade Two tungsten steel blades
Driving System Air
Foot Pedal Yes
Roll Holder Yes
Machine Size 2175*580*1050mm
